Emerson Process Management GmbH & Co. OHG 3-9
X-STREAM XEFD
Instruction Manual
HASXEDE-IM-EX
03/2012
3
Startup
3.6 Software
Some menus have more entries than can dis-
played at once. In these menus, an indicator
in the last () and/or rst () line indicates the
direction the menu continues in.
In the example to the left
• page 1
continues downwards
• page 4
continues upwards and downwards
• page 8 continues upwards.
To show the next page (indicator )
• place the cursor in the last accessible line
and press down or
• press right, irrespective of where the cursor
is located.
To show the previous page (indicator )
• place the cursor in the rst accessible line
and press up or
• press left, irrespective of where the cursor
is located.
Browsing
Program Sequence 1of8
Action1: END-OF-PGRM
Node1: All
Action2: END-OF-PGRM
Node2: All
Action3: END-OF-PGRM
Node3: All
Action4: END-OF-PGRM
Node4:
All
Program Sequence 4of8
Action13: END-OF-PGRM
Node13: All
Action14: END-OF-PGRM
Node14: All
Action15: END-OF-PGRM
Node15: All
Action16: END-OF-PGRM
Node16:
All
Program Sequence 8of8
Action29: END-OF-PGRM
Node29: All
Action30: END-OF-PGRM
Node30: All
Page 1
Page 4
Page 8
To Next Page
