5-10 Assembly\Disassembly
CadJet 3D Service Manual
Install Memory (SIMM)
NOTE
If you are installing two SIMM, you must install the one
located in J17 first. See Figure 3-4 for location.
1. The SIMM slots are at a 90° angle from the board. Place the SIMM
at a 45° into the connector as shown in Figure 5-5.
2. Slowly push the SIMM up to a 90° angle until the two side clips
snap into place. Make sure the SIMM is fully seated.
3. Perform steps 4 through 10 of the Install the Left, Top, and Right
Covers procedure to install the Right and Top Covers.
Remove the MPCB (Main Printed Circuit Board)
Integrated circuits may become weakened or damaged by
electrical discharge. Do not touch or work near integrated
circuits without wearing an ESD wrist strap.
1. Perform steps 1 through 9 of the Remove the Left, Top, and Right
Covers procedure to remove the Top and Right Covers.
2. Put on an ESD wrist strap.
3. Perform step 2 of the Remove Memory (SIMM) procedure to remove
any memory that was added.
