ENCAD CADJET - Setting up Tools from Height Gauge Kit

3-20 Maintenance
CadJet 3D Service Manual
Figure 3-13. Carriage Head Height Tolerance.
1. Remove the lid and the right cover of the printer. See Chapter 5
for procedures.
2. Obtain the 3 tools (Micrometer Dial Gauge, Test Cartridge, and
Measuring Tip Extender) from the Height Gauge Kit. Assemble
the tools as shown in Figure 3-14.
Figure 3-14. Setting Up Tools from Height Gauge Kit.
