6-2 Parts List
CadJet 3D Service Manual
6-1 1 COVER W/DOOR, LEFT ......................... 209220-10
6-1 2 RESERVIOR ASSEMBLY, WITH
CAP AND TUBE ASSEMBLY
BLUE .................................................... 212176-00
6-1 3 CAP, RESERVIOR ................................... 207562
6-1 4 TUBE ASSY, RESERVIOR, BLUE .......... 209580
6-1 5 INK DELIVERY SYSTEM ....................... 215048-00
6-1 6 FITTING, FEMALE, BLUE .................... 212244-00
6-1 7 C-RING, 7/16 SHAFT .............................. 207789
6-1 8 SIDE PLATE, LEFT ................................ 212763-00
6-1 9 BASE PLATE, LEFT ............................... 210544
HARDWARE KIT ..................................... 208810
ASSEMBLY, NOVAPRIME...................... 213092-00
SIMM, 32MB, 72 PIN .............................. 210610
ASSY, HEIGHT GAGE KIT..................... 209996-1
LOOPBACK TEST CABLE ...................... 205462
FIGURE ITEM PART NAME PART #
