5. Slightly loosen the screws located on the back of the Y-arm that
secures the stabilizer to the Y-arm.
Damage may occur to the micrometer
gauge if the Carriage is moved without
lifting up on the measuring tip. This ac-
tion could also take the micrometer out
of alignment and foul the results of the
alignment.
6. While lifting up the measuring tip of the micrometer, slide the
Carriage to the left side of the stabilizer. Position it as close to
the screw as possible and drop the measuring tip onto the
platen. Do this a couple of times to ensure an accurate reading.
7. Move the left end of the stabilizer bracket until the reading
below is observed. Read only the RED numbers on the
micrometer gauge.
For these printers adjust for a reading of 67 +/- 3. This equates
to a head height of 0.075”.
