3-36 Maintenance
CadJet 3D Service Manual
Continuous Test - The Continuous Test sends the printer into a test
loop that will perform a series of tests continuously. Powering
down and restarting the printer is the only way of exiting this
test loop.
The Continuous Test will first prime the cartridges, followed by
a serial port test, parallel port test, a fast deadband display and
a color calibration display.
The deadband and color calibration displays are used only as a
visual inspection of the operating condition of the printer. No
adjustments can be performed while in the Continuous Test
mode.
A loopback Test Cable is required to correctly accomplish the
serial and parallel port tests. Install both ends of the Loopback
Cable before running this test. The Loopback Test Cable is
listed in Chapter 6.
After completing the deadband display, the test will begin again
with the prime and continue until power is removed.
Fan #1 Test - Tests the operation of the fans on the printer. Fan #1
Test (while depressed) turns on the power supply cooling fan
and the suction fan inside the platen.
Fan # Test - Fan #2 Test is disabled for this printer.
Legs Test - Legs Test is disabled for this printer.
