Function and design PlasmaQuant 9100 (Elite)
22
3.4 ASPQ 3300 sampler
Figure14ASPQ 3300 sampler
The sampler facilitates fully automatic routine analysis. It can be equipped with 3 sam-
ple racks and 2
racks with 6 special samples, e.g. standard solutions.
The following sample racks are available:
Rack/number of samples Vessel volume
6 (special vessels) 50 ml
21 50 ml
24 30 ml
40 20 ml
60 14 ml
7 ml 7 ml
The purging vessel is installed on the sampler. The hose pump at the sampler pumps the
purging liquid from the storage bottle into the purging vessel – this action cleans the in-
serted cannula by cleansing it inside and out. Excess purging liquid is pumped into the
waste container during purging. The purging liquid for between measuring breaks or for
special purging steps within a measuring routine is also taken from the purging vessel.
A power connection supplies operating voltage to the sampler.
