Installation and commissioning PlasmaQuant 9100 (Elite)
28
4.1.6 Device layout and space requirements
The emission spectrometer is a compact device designed for table-top operation. The re-
quired space depends on all the components that make up the measuring station.
Components of the measuring station:
¡ Sampler
¡ Recirculating chiller
¡ Waste bottle (under the workbench)
¡ The PC and printer may be placed on a separate side table.
The workbench must meet the following requirements:
¡ The minimum dimensions of the workbench for the device and sampler are
1800 mm x 750 mm
. Additionally, a clearance of 300 mm must be maintained be-
tween the rear of the device and the adjacent wall.
¡ The height can be chosen according to ergonomic aspects.
¡ The device must be freely accessible from all sides.
¡ The workbench must be capable of bearing a load of at least 200 kg.
¡ The workbench surface must be wipe, scrape and corrosion resistant and must not
absorb moisture.
Component Width x Height x Depth [mm] Mass [kg]
On the workbench
Basic device 990 mm x 940 mm x 855 mm 170 kg
ASPQ 3300 sampler 285 mm x 510 mm x 490 mm 15 kg
Teledyne Cetac ASX-560 sam-
pler
580 mm x 620 mm x 550 mm 12 kg
Cetac Oils 7400 sampler 570 mm x 490 mm x 540 mm 23 kg
Teledyne Cetac SDX(HPLD) dilu-
tion system
132 mm x 254 mm x 117 mm 4.4 kg
Cetac ASXPress Plus switching
valve with control unit
58 mm x 128 mm x 217 mm
83 mm x 254 mm x 200 mm
1.3 kg
1.4 kg
Outside of the laboratory or next to the workbench
Water-air cooler 460 mm x 703 mm x 735 mm 92 kg
Water-water cooler 360 mm x 590 mm x 470 mm 33 kg
(empty)
Under the workbench
Waste bottle (⌀ x height) 120 mm x 250 mm
For unimpeded cooling air circulation and effective cooling, the side housing surfaces
water-air cooler require a minimum distance of 60 cm
from adjacent objects. Due to the
dissipated heat and possible noise generated, the water-air cooler should be placed out-
side the laboratory. Extension of the cooling water hoses is permitted if the minimum
pressure and flow volume are maintained.
