Specifications PlasmaQuant 9100 (Elite)
84
Ambient conditions
Temperature range +15 °C to +35 °C,
optimal is +20 °C to +25 °C
, as constant as possi-
ble during measuring operations
Max. humidity 20 to 90 % at 20 °C
Air pressure 0.7 bar to 1.06 bar
Max. permissible altitude 2000 m
Storage Temperature: -40 °C to +70 °C
Use dessicant
Dimensions and weight
Dimensions (W x
H x D)
990 mm x 940 mm x 855 mm
Weight 170 kg
10.1.2 Control computer technical data
Minimum require-
ments for the con-
trol computer
PC with Windows 8.1 or Windows 10 (32/64 Bit)
Graphics resolution 1280 x 1024
(1024 x 768
possible with restrictions), Direct X 9, WDDM 2.0
Processor: 1.6 GHz Dual Core CPU
RAM: 2 GB RAM (32 Bit), 4 GB RAM (64 Bit)
Hard drive space: 4 GB (SSD recommended)
4 x USB 2.0 interfaces
Mouse / trackball, keyboard
A CD/DVD drive is required for installation.
10.1.3 Recirculating chiller technical data
Water-air cooler
Tank capacity 3.5 l
Dimensions (W x H x D) 460 mm x 703 mm x 735 mm
Supply voltage / frequency 110 V / 60 Hz
230 V / 50/60 Hz
Typical average power con-
sumption
2900 VA
Cooling performance 3000 VA at 25 °C
Mass (empty) 92 kg
Silent Version (optional),
noise level
≤ 57 dB
¡ Length of the water
hoses
¡ Length of the power
cable
(For placement in adjacent
rooms)
¡ 3 m
¡ 2.7 m
