PlasmaQuant 9100 (Elite) Specifications
85
Water-water cooler
Tank capacity 5 l
Dimensions (W x H x D) 360 mm x 590 mm x 470 mm
Supply voltage / frequency 230 V / 50 Hz
Typical average power con-
sumption
160 VA
Cooling performance 3500 VA at 20 °C
Mass (empty) 33 kg
Noise level ≤ 50 dB
Max. water inlet flow tem-
perature (primary side)
15 °C
Required water quantities 610 l/h (for 15 °C water temperature on the inlet
side, 20 °C
on the outlet side and Δp=40 kPa)
10.1.4 ASPQ 3300 sampler technical data
Dimensions (W x H x D) 285 mm x 510 mm x 490 mm
Mass 15 kg
Supply voltage, frequency 100 to 240 V, 50/60 Hz
Fuse T 5 A H 250 V, 5 x 20 mm
Typical average power con-
sumption
75 VA
Racks 3 (sample vessels)
2 (special vessels)
Purging bottle 2 l
10.1.5 Technical data for other accessories
Sampler
Teledyne Cetac ASX-560 Dimensions
(W x H x D)
580 mm x 620 mm x 550 mm
Mass 12 kg
Cetac Oils 7400 Dimensions
(W x H x D)
570 mm x 490 mm x 540 mm
Mass 23 kg
Dilution system
Teledyne Cetac SDX(HPLD) Dimensions
(W x H x D)
132 mm x 254 mm x 117 mm
Mass 4.4 kg
