Proline Promass E 100 Modbus RS485 Electrical connection
Endress+Hauser 35
Depending on the device version: are all the device plugs firmly tightened →  30? 
• Does the supply voltage match the specifications on the transmitter nameplate →  86?
• For device version with Modbus RS485 intrinsically safe: does the supply voltage match the
specifications on the nameplate of the Safety Barrier Promass 100 →  86?

Is the terminal assignment →  25 or pin assignment of the connector →  28 correct? 
• If supply voltage is present, is the power LED on the electronics module of the transmitter lit
green →  11?
• For device version with Modbus RS485 intrinsically safe, if supply voltage is present, is the
power LED on the Safety Barrier Promass 100 lit →  11?

Depending on the device version, is the securing clamp or fixing screw firmly tightened? 
