SS500/SS2000 Analyzer
1–8 4900002285 rev. B 3-25-20
Getting Familiar with the Analyzer
The SS500 and SS2000 are single-channel analyzers designed to continuously
measure the moisture content in natural gas pipelines. The SS2000 offers
higher measurement performance in those applications, and its single
measurement channel can also be configured to monitor CO
2
levels in natural
gas pipelines, or to measure the moisture content in CO
2
pipelines. For
performance specifications, refer to Table A–1 and Table A–2.
SpectraSensors’ SS500/SS2000 analyzers are typically comprised of a single
electronics enclosure and associated measurement cell(s). Refer to Appendix A
for the system drawings. On the front panel of the analyzer, the keypad and
LCD display serve as the user interface to each analyzer. The analyzer control
electronics drive the laser, collect the signal, analyze the spectra and provide
measurement output signals. Refer to Figure 1–5.
Power is connected to the analyzer from an external power source through the
bottom of the enclosure. The measurement cell along with flow devices to
control flow and pressure for the measurement cell and the bypass loop may
be mounted on a panel alongside the electronics enclosure.
Fuses
Inside the SS500/SS2000 analyzer electronics enclosure is the electronics
assembly. Fuses are located on the electronics control board, as shown in
Figure 1–6 and Figure 1–7
.
Figure 1–5 Analyzer Overview (SS500/SS2000
pictured)
LCD/KEYPAD
MEASUREMENT
CELL AND LASER
POWER CONNECTION
ELECTRONICS
ENCLOSURE
