1. Application dependent.
Table A-1 SS2100 H
2
S analyzer specifications (Continued)
Electrical & Communications (Continued)
DO Contact Rating
(Inductive Load)
250 VAC, 3 A NO contact, 1.5 A NC contact
24 VDC, 1A NO and NC contact
LCD Display Concentration, cell pressure, temperature and
diagnostics
Digital Output (5): Concentration Alarm, General Fault, Validation
Fail
1
, Validation 1 Active
1
, Validation 2 Active
1
Communication Analog: (2) 4-20 mA Isolated, 1200 ohms at 24 VDC
maximum (concentration only) — Optional
Serial: RS-232C and Ethernet
Protocol: Modbus Gould RTU or Daniel RTU or ASCII
Physical Specifications
Size (typical)
1
1300 to 1500 mm H 600 to 920 mm W 300 to 450
mm D
(50 to 60 in. H 24 to 36 in. W 12 to 17 in. D)
Weight (typical)
1
Approximately 59 Kg (130 lbs) with Sample System
Electronics and Sample
System Enclosure
Built with NEMA 4X 304 or 316L stainless steel
enclosure
Sample Cell Construction 316L Series polished stainless steel — standard
Area Classification
Analyzer with Sample
Conditioning System (SCS)
Class I, Division 2 Group A, B, C, D T3 / T3C
Class I, Zone 2 IIC T3 / T3C
Type 4X, IP66
For a complete listing of new or updated certificates, please visit
the product page at www.endress.com.
Configurations requiring optional accessories, e.g., probe
assemblies, with specific characteristics must meet manufacturer
specifications.
