BA02191C SS2100 TDLAS H
2
S Gas Analyzer
Endress+Hauser 3-3
Mounting the Analyzer
The SS2100 H
2
S analyzer is manufactured for wall installations. The analyzer
is constructed with four mounting brackets, two on the top of the sample
conditioning system (SCS) cabinet and two on the bottom. Refer to Figure 3–1
on page 3–4 and the layout diagrams in Appendix A for detailed mounting
dimensions.
Lifting/carrying the analyzer
Due to the analyzer’s size and weight (configurations can weigh approximately
59 Kg or 130 lbs), the use of a forklift, pallet jack, etc. is recommended to lift
and/or move the analyzer. If the analyzer is to be lifted by hand, designate
multiple individuals and distribute the weight among personnel to avoid injury.
Before removing from the crate, move the analyzer as close as possible to the
final installation location. Never lift the analyzer by the electronics enclosure.
Always carry the load using one of the following points/methods (refer to
Figure 3–1 on page 3–4):
• Mounting points
• Support beneath instrument (best used when employing a forklift)
To mount the analyzer
1. Select a suitable location to mount the analyzer. Choose a shaded
area or use an optional analyzer hood (or equivalent) to minimize
sun exposure to the fully mounted analyzer. Refer to
“Lifting/carrying the analyzer” on page 3-3.
When mounting the analyzer, be sure to position the instrument
so that it is not difficult to operate adjacent devices. Allow three
feet (1 meter) of room in front of the analyzer and any switches.
It is critical to mount the analyzer so that the supply and return
lines reach the supply and return connections on the chassis,
while still maintaining flexibility, so that the sample lines are not
under excessive stress.
Ensure all equipment used for lifting/moving the analyzer is rated
for the weight load.
Endress+Hauser analyzers are designed for operation within the
specified ambient temperature range. Intense sun exposure in
some areas may cause the analyzer temperature to exceed the
maximum.
