BA02191C SS2100 H
2
S TDLAS Gas Analyzer
Endress+Hauser B-9
Tools and materials
• Acetone-impenetrable gloves (North NOR CE412W Nitrile Chemsoft™
CE Cleanroom Gloves or equivalent)
• 9/16 in. wrench
• 7/8 in. wrench
• 9/64 in. Allen wrench
• Flat-head screwdriver
• Phillips-head screwdriver
• Metal pick
• Military grade stainless steel PTFE tape (or equivalent)
• Dry nitrogen
• Isoproypl alcohol
To replace the pressure sensor
1. Close the external flow of gas to the sample conditioning system
(SCS) at the sample inlet.
2. Purge the system by connecting dry nitrogen to the sample inlet.
Allow the SCS to purge for 5 to 10 minutes.
3. Close the nitrogen flow.
4. Power off the system. Refer to the Description of Device Parameters
for this analyzer for “Powering down the analyzer”.
5. Open the door to the SCS enclosure. Refer to Figure B–3 on page
B–10.
6. Remove the optical cable harness using a flat-head screwdriver.
7. Disconnect the cell inlet using a 9/16 in. wrench.
8. Disconnect the cell outlet using a 9/16 in. wrench.
9. Disconnect the thermistor cable at the circular connector.
10. Remove the pressure sensor cable from the circular connector inside
the enclosure.
For new model pressure sensors with quick-disconnects, detach the
pressure sensor cable from the pressure sensor at the connector
using a Phillips-head screwdriver. Do not remove the black connector
from the cable inside the enclosure.
Isopropyl alcohol can be hazardous. Follow all safety precautions
when in use and thoroughly wash hands prior to eating.
