Installation and Operation Manual - DustEx Menu Overview and Explanations
Doc.-ID: COM_OXI_Dust_11022020 7
Limit alarms
Limit alarm 1 (O
2
)(OFF/ON)
♦ at
} visible when set to "ON"
♦ hysteresis
Limit alarm 2 (COe)(OFF/ON)
♦ at
} visible when set to "ON"
♦ hysteresis
O
2
sensor calibration values
O
2
cal.value - offset (mV)
O
2
cal.value - slope (mV/dec)
COe measuring range
Measuring range from (ppm / mg/m
3
)
Measuring range to (ppm / mg/m
3
)
Measuring value averaging for (s)
mA output on system errors (mA)
COe sensor calibration values
COe cal. value: offset
COe cal. value: alpha
COe cal. value: beta
COe cal. value: gamma
COe cal. value: delta
COe cal. value: SO
2
correction value
Calibration settings
Time per test gas apply (Min.)
Delay time to process (Min.)
Pre-purge time (Min.)
Measurement value hold on calibration (ON/OFF)
Auto calibration (ON/OFF)
♦ Calibration method (1-Point / 2-Point /O
2
+COe) } visible when set to "ON"
♦ Test gas1 (bottle value % O
2
) { when preset to 2-point} } visible when set to "ON"
♦ Test gas 2 (bottle value ppm CO) { when preset to 2-point} } visible when set to "ON"
♦ Start by (Time, dig. Input, both)
♦ Interval (days)
} not applicable with dig.input
♦ next ACAL at (set date)
To Next Page
