Configure data inputs
Instruction manual Ensite Pro Configuration Tool Page 19
Gauge types ‘816' and ‘818' are only supported via 858 CIU.
Gauge type ‘829' is only supported in 867 emulation mode.
All three gauge types require the extended field address for 858 CIU
or 867 receiver (TOI 858 = P or R, TOI 867 = L).
Gauge type ‘999' is a generic Enraf gauge with no special
processing (default processing used).
General limits:
All instruments from one tank must be connected to the same
FieldPort.
Using BPM cards:
Up to 50 data inputs can be equally divided over the four FieldPorts
of the CIU Prime, with a maximum of 15 data inputs per line.
The instrument address on each port is free selectable between
00...99. The instrument address must be unique for all data inputs on
the same CIU.
Using RS232/485 cards:
Field addresses may contain 3 digit address numbers.
Gauge
Gauge type
Select:: Unknown, 802, 811, 812, 813, 816, 818, 829, 854, 865,
866, 872, 873, 877, 894, 973 or 999
Gauge details Select:: h for 854 gauges using the ZLQ record
(up to software version SPUA1.0)
- for 854 gauges
(with software version SPUA2.0 onwards)
Allowed gauge commands
Test gauge
Check if allowed (TG; 811, 854, 894 only)
Block gauge Check if allowed (BL; 811, 854, 894 only)
Tank profile Check if allowed (TP; 854, 894 only)
Gauge alarm test Check if allowed (AT; 873 only)
Lock test Check if allowed (LT; 811, 854, 894 only)
Water dip Check if allowed (I3; 811, 854, 894 only)
Interface profile Check if allowed (IP; 854, 894 only)
Verify command Check if allowed (CA; 854, 894 only)
Reset gauge Check if allowed (RS)
Interface 2 command Check if allowed (I2; 854, 894 only)
