Configure CIU Prime
Instruction manual Ensite Pro Configuration Tool Page 41
If ‘RS-232C’ is selected, while in reality RS-485 hardware is applied,
communication can not be established.
Modbus mapping
CIU Plus compliant
Select if there is a CIU Plus connected to this port. All data will be
filled in on pre-defined positions.
W&M sealed
Check if applicable
User specified
Select if there is no CIU Plus connected to this port. All data will be
filled in on user specified positions.
Press the ‘Settings’-button to program these positions
(refer to the second next chapter, ‘Modbus settings’).
CIU 858 compatible
Check to enable CIU emulation
MSU mode
Check to enable
Stop bits
Select: 1 or 2
Parity
Select: Odd, Even or None
Turn-around delay
Enter reply waiting time in ms (default = 100 ms)
Duplex mode
Select: Full or Half
Mode
Select: RS-232C or RS-485
Multi Party
Select: Point-to-point or Multi-drop
