Overview
1-2 Introduction
C2G124-48P Stackable Switch
TheC2G124‐48P(Figure 1‐1)hasseveraltypesoffrontpanelportconnections,which
include:
•Forty‐eightRJ45ports(10/100/1000Mbps,1000BASE‐Tcopperports)thatalso
supportPoEforconnectionstonetwork803.2afcompliantPDs(powereddevices).
•SFPslotsthatprovideyouwiththeoptionofinstallingSmallFormPluggable
(SFP)
Mini‐GBICsfor1000BASE‐Tcompliantcopperconnectionsor1000BASE‐SX/LXfiber‐
opticconnections.
•Rearpanelconnectorsforhigh‐speedconnectionsinastackconfiguration.
•RearpanelRedundantPowerSupplyconnectorusedtoconnecttoaSecureStackC2
PoERedundantPowerSupply(C2RPS‐POE).TheswitchconnectstotheC2RPS
‐POE
usingaC2RPS‐POECable.
The10/100/1000 Mbpsfixedfrontpanelportscanoperateineitherhalf‐duplexorfull‐
duplexmode,asdeterminedbyAuto‐Negotiation.
Note: The Mini-GBIC ports cannot be active simultaneously with their corresponding
10/100/1000BASE-T ports. For example, if SFP port 48 establishes a link first on the
C2G124-48P, the 10/100/1000BASE-T built-in RJ45 port 48 is not available and
vice-versa.
Caution: The C2G124-48P is a PoE-compliant device. Do not connect a SecureStack C2
Redundant Power System (C2RPS-SYS) to the power connector. Otherwise, damage to
the device may result.
Precaución: El dispositivo C2G124-48P cumple con el estándar PoE. No conecte una
fuente de poder redundante SecureStack C2 (C2RPS-SYS) al cable de corriente directa.
De lo contrario, el dispositivo puede dañarse.
