Connecting to Console Port for Local Management
SecureStack C2 Installation Guide 3-19
Figure 3-10 Connecting an IBM PC or Compatible
Connecting to a VT Series Terminal
ToconnectaVTSeriesterminaltoanEnterasysswitchConsole port(Figure 3‐11),usea
UTPserialinterfacecableterminat edwithaDB9femaleconnectorandaDB25female
connectorandproceedasfollows:
1. ConnecttheDB9female connectoratoneendofcabletotheConsoleporton
the
Enterasysswitch.(Ifthereisaswi tchdesignatedastheManager,connecttoits
Consoleport.)
2. PlugtheDB25femaleconnectorattheotherendofthecableintotheportlabele d
COMMontheVTterminal.
3. TurnontheterminalandaccesstheSetupDirectory.Setthefollowingparameterson

yourterminal:
Whentheseparametersare set,theStartupscreenwilldisplay.Proceedto“Connectingto
theNetwork”onpage 3‐21.
1 DB9 female cable connector 4 DB9 female connector
2 Serial interface cable 5 PC with VT emulation application
3 DB9 male Console port connector
C2G124-24
Console
45
46
47
48
C2G124-48P
45 46
47
48
ÂÃ
Á
À
Ä
Parameter Setting
Mode 7 Bit Control
Transmit Transmit=9600
Bits Parity 8 Bits, No Parity
Stop Bit 1 Stop Bit
