Installing the Switch on a Flat Surface
SecureStack C2 Installation Guide 3-7
Installing the Rubber Feet
Toinstalltherubberfeet,refertoFigure 3‐3andproceedasfollows:
1. Placetheswitchonitsbackonasturdyflatsurfacetogainaccesstothebottomofthe
chassis.
2. Removethefourrubberfeetfromtheirplasticbagintheshippingbox.
3. Locatethefourmarkedlocationson
thebottomfou r cornersofthechassis.
Figure 3-3 Chassis Bottom, Rubber Feet Placement
4. Removetheprotectivestripfromthebackofonerubberfootandpositionitona
markedlocationandpressfirmlyintoplace.Repeatthisproceduretoinstallthe
remainingthreerubberfeet.
5. Afterinstallingtherubberfeet,returntheswitchtoits
uprightposition.
6. Toinstallswitchesonaflatsurfaceproceedto“GuidelinesforFlatSurface
Installation”onpage 3‐8.Forarackmountinstallation,proceedto“RackMounting
theSwitch”onpage 3 ‐9.
1 Bottom of chassis as seen when chassis is resting on
its back
3 Rubber feet with adhesive backing
(four)
2 Locations to install the rubber feet (four locations)
Note: If a number of switches are being installed in a stack, repeat steps 1 through 4 to
install the rubber feet on each switch before continuing with the installation.
