Connecting to the Network
SecureStack C2 Installation Guide 3-23
d. EnsurethatthetwistedpairconnectionmeetsthedBlossandcablespecif ications
outlinedintheCablingGuide.Referto“RelatedDocuments”onpage xvifor
informationonobtainingthisdocument.
5. IfalinkisnotestablishedorthereisnoPoEpower,contactEnterasys Networks.Refer
to“GettingHelp”on
page 1‐7fordetails.
Repeatallstepsaboveuntilallconnectionshavebeenmade.
Figure 3-14 Four-Wire Crossover Cable RJ45 Pinouts for 10/100BASE-TX
Figure 3-15 Four-Wire Straight-Through Cable RJ45 Pinouts for 10/100BASE-TX
1 RJ45 switch port 3 RJ45-to-RJ45 crossover cable
2 Other device port 4 RX+/RX- and TX+/TX-connections
These connections must share a common color pair.
1 RJ45 switch port 3 RJ45-to-RJ45 straight-through cable
2 Other device port 4 RX+/RX- and TX+/TX-connections
These connections must share a common color pair.
TX+
TX
RX+
RX 2
1
3
6
TX+
TX
2
1
3
6
RX+
RX
