Envision One cDLM® User Manual
TS-MAM-EnvisionOneCDLMUserManual-V5.0-FN-EN , 2021-12-15
10.3 Loading a Job File
To load a job to the printer:
1. Enter Run into the Windows search field or use <Windows> + <R> hotkey on your computer keyboard.
→ The Run window opens.
2. Enter the IP address of the printer, e. g.: \\10.0.0.24.
→ The Windows file explorer opens, showing the folders on the printer.
3. Open the Job folder.
4. Put the job files to the folder.
→ All the files from Job folder are now shown in the Job List tab.
10.3.1 Loading a Job via FTP
To load a job to the printer:
1. Enter the IP address of the printer, e. g.: ftp://10.0.0.114.
→ The Windows file explorer opens, showing the folders on the printer.
2. Open the Job folder.
3. Put the job files to the folder.
→ All the files from Job folder are now shown in the Job List tab.
10.3.2 Loading a Job from USB Drive
To save a Job to USB drive, follow the next steps:
1. Connect the USB-drive to the PC with the installed Envision One RP.
2. Open the Envision One RP.
3. Create the job you want to save.
4. Select the job you want to save.
5. Click Print.
→ The following window appears:
1. Click Save job.
→ The folder selection dialog box appears.
2. Open the USB-drive folder you want to save a job to and click Select Folder.
