5050 CONTROL UNIT
Technical Manual & Cabling Instructions
15 / 92
19.10.2012
5050 / MAN000539
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
X3.24
Power2 Supply
X3.25
Power2 Supply
X3.26
PWM/DO/DI/CM_Type007 12k4 GND P2 / S Nominal current 2,5 A
X3.27
PWM/DO/DI/CM_Type007 12k4 GND P2 / S Nominal current 2,5 A
X3.28
PWM/DO/DI/CM_Type008 12k4 GND P2 / U Nominal current 2,5 A
X3.29
PWM/DO/DI/CM_Type008 12k4 GND P2 / U Nominal current 2,5 A
X3.30
PWM/DO/DI/CM_Type008 12k4 GND P2 / X Nominal current 2,5 A
X3.31
PWM/DO/DI/CM_Type008 12k4 GND P2 / X Nominal current 2,5 A
X3.32
PWM/DO/DI/CM_Type008 12k4 GND P2 / V Nominal current 2,5 A
X3.33
PWM/DO/DI/CM_Type008 12k4 GND P2 / V Nominal current 2,5 A
X3.34
PWM/DO/DI/CM_Type008 12k4 GND P2 / Y Nominal current 2,5 A
X3.35
PWM/DO/DI/CM_Type008 12k4 GND P2 / Y Nominal current 2,5 A
