Epec 5050 User Manual

5050 CONTROL UNIT
Technical Manual & Cabling Instructions
14 / 92
19.10.2012
5050 / MAN000539
Epec Oy reserves all rights for improvements without prior notice
Epec Oy Postiosoite/Postal address Puhelin/Phone Fax Internet
Tiedekatu 6 PL/P.O.Box 194 +358-(0)20-7608 111 +358-(0)20-7608 110 www.epec.fi
FIN-60320 Seinäjoki FIN-60101 Seinäjoki, Finland
X2.23
AI/DI_Type011
2.2k +10 V / 220R GND / 47k5
GND
0/4..20 mA 0..10 V
X2.24
Power1 Supply
X2.25
Power1 Supply
X2.26
DO_GNDType010 12k4 GND P1 Nominal current 3 A
X2.27
DO_GNDType010 12k4 GND P1 Nominal current 3 A
X2.28
PWM/DO/DI/CM_Type007 12k4 GND P2 / O Nominal current 2,5 A
X2.29
PWM/DO/DI/CM_Type007 12k4 GND P2 / O Nominal current 2,5 A
X2.30
PWM/DO/DI/CM_Type007 12k4 GND P2 / R Nominal current 2,5 A
X2.31
PWM/DO/DI/CM_Type007 12k4 GND P2 / R Nominal current 2,5 A
X2.32
PWM/DO/DI/CM_Type007 12k4 GND P2 / T Nominal current 2,5 A
X2.33
PWM/DO/DI/CM_Type007 12k4 GND P2 / T Nominal current 2,5 A
X2.34
DO_GNDType010 12k4 GND P1 Nominal current 3 A
X2.35
DO_GNDType010 12k4 GND P1 Nominal current 3 A
X3.1
Power2 GND
X3.2
Power2 GND
X3.3
GND
X3.4
GND
X3.5
DI/PI_Type003 2k2 +10 V / 12k4 GND j
Min input freq.
configurable
X3.6
DI/PI_Type003 2k2 +10 V / 12k4 GND j
Min input freq.
configurable
X3.7
DI/PI_Type002 12k4 GND
X3.8
DI/PI_Type003 2k2 +10 V / 12k4 GND k
Min input freq.
configurable
X3.9
DI/PI_Type003 2k2 +10 V / 12k4 GND k
Min input freq.
configurable
X3.10
DI/PI_Type002 12k4 GND
X3.11
DI/PI_Type003 2k2 +10 V / 12k4 GND l
Min input freq.
configurable
X3.12
DI/PI_Type003 2k2 +10 V / 12k4 GND l
Min input freq.
configurable
X3.13
REF +10V_Type004 +10 V 250 mA
X3.14
AI/DI_Type011
2.2k +10 V / 220R GND / 47k5
GND
0..22 mA 0..10 V
X3.15
AI/DI_Type011
2.2k +10 V / 220R GND / 47k5
GND
0..22 mA 0..10 V
X3.16
AI/DI_Type011
2.2k +10 V / 220R GND / 47k5
GND
0..22 mA 0..10 V
X3.17
AI/DI_Type011
2.2k +10 V / 220R GND / 47k5
GND
0..22 mA 0..10 V
X3.18
AI/DI_Type011
2.2k +10 V / 220R GND / 47k5
GND
0..22 mA 0..10 V
X3.19
AI/DI_Type011
2.2k +10 V / 220R GND / 47k5
GND
0..22 mA 0..10 V
X3.20
REF +5V_Type015 +5 V 350 mA
X3.21
DI/PI_Type003 2k2 +10 V / 12k4 GND m
Min input freq.
configurable
X3.22
DI/PI_Type003 2k2 +10 V / 12k4 GND m
Min input freq.
configurable
X3.23
DI/PI_Type003 2k2 +10 V / 12k4 GND a
Min input freq.
configurable
