The following tables provide more detailed descriptions about the performed EMC tests:
Emission tests according to the E/ECE Regulation No. 10, Revision 3 (2008)
Radiated disturbance emission test
• Test method E/ECE Reg. No. 10, Annexes 7 and 8
Frequency
(MHz)
Limit value (dBmV/m)
30 – 1000
62/52/63
(Broadband QP)
30 – 1000
52/42/53
(Narrowband AVE)
Conducted disturbances emission test
• Test method E/ECE Reg. No. 10, Annex 10, ISO 7637-2:
2004
Port Limit level (V)
12V DC input
+75
-100
24V DC input
+150
- 450
