Immunity tests according to the E/ECE Regulation No. 10, Revision 3 (2008)
Immunity to transient disturbances
conducted along supply lines test
• Test method E/ECE Reg. No. 10, Annex 10, ISO 7637-2:
2004
• Performance criterion:
Pulse Criterion
1
C
2a
B
2b
C
3a
A
3b
A
4
C
5
C
• 24 V input, Pulse:
Pulse Pulse parameters
1 3/2000 μs, -600 V, 5000 pulses
2a
1/50 μs, +112 V, 5000 pulses
2b
20V, 220 ms, 10 pulses
3a
5/100 ns, -300 V, 60 minutes
3b 5/100 ns, +300 V, 60 minutes
4 100 ms -20.5 (8.0) V, 20 s -16.5
(12.0) V,
10 pulses
5 +70V 5 pulses
• 12 V input, Pulse:
Pulse Pulse parameters
1
1/2000 μs, -150 V, 5000 pulses
2a
1/50 μs, +112 V, 5000 pulses
2b
10V, 220 ms, 10 pulses
3a
5/100 ns, -212 V, 60 minutes
3b
5/100 ns, +150 V, 60 minutes
4 25 ms -6.0 (8.0) V, 5 s -2.5 (12.0) V,
10 pulses
5
+70V 5 pulses
