Epson SC-F9200 series Service Manual

SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 165
SE Group Confidential (Related Staff Only)
C H E C K
P O I N T
Regarding to SC-F9200 series which have films to extend life, Pass
the cable of sensor into clamp like
Figure 3-105 .
 Printers which have films to extend life:There are 2 labels.
 Printer which don’t have films not to extend life:There are 1 label.
Figure 3-105. How to wire CR HP sensor
Clamp
Clamp
Cable
