Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
TROUBLE SHOOTING Remedies for Service Call Error 45
SE Group Confidential (Related Staff Only)
113A
CR Motor
overload error
Overcurrent to the CR Motor was detected.
 CR Encoder cable is damaged.
 CR Motor cable is damaged.
 Irregular load
 CR Encoder failure
 CR Motor failure
1. Is the CR Unit being attached correctly?
2. Is there any foreign materials on the CR Unit drive
path?
3. Is there any problems such as damaged cable in the
connections below?
 CR Encoder to SUB Board (CN102)
 CR Motor to SUB-M Board (CN1)
4. Does the CR Encoder work properly? Check it
using the Service Program.
1. Re-install the CR Unit. (Page 200)
2. Replace the CR Encoder. (Page 166)
3. Replace the CR Motor. (Page 161)
113B
CR Motor
over speed error
The CR Motor was driven at a speed faster than a
predetermined one during deceleration.
 Irregular load
 CR Encoder failure
 SUB Board is damaged.
 CR Motor driver failure
Does the CR Encoder work properly? Check it using
the Service Program.
1. Replace the CR Encoder.
(Page 166)
2. Replace the SUB Board. (Page 131)
3. Replace the Main Board. (Page 123)
113C
CR Motor
reversing error
The number of occurrences of reversing the CR
Motor has reached a predetermined limit.
 The polarity of CR Encoder cable is opposite.
 The polarity of CR Motor cable is opposite.
 Slipping of the teeth of CR Timing Belt
 CR Encoder failure
1. Is there any problems such as damaged cable in the
connections below?
 CR Encoder to SUB Board (CN102)
 CR Motor to SUB-M Board (CN1)
2. Is the tension of the CR Timing Belt proper?
3. Does the CR Encoder work properly? Check it
using the Service Program.
1. Adjust the tension of the CR Timing Belt.
(Page
297)
2. Replace the CR Encoder. (Page 166)
113D
CR Motor
driving time-out error
Abnormally-long driving duration of the CR Motor
was detected.
 Irregular load
 Firmware becomes out of control.
---
Replace the Main Board. (Page 123)
113E
CR Motor
velocity deviation error
The CR Motor was driven at a speed abnormally
faster than a predetermined one during acceleration or
deceleration.
 Irregular load
 CR Encoder failure
 CR Motor failure
 SUB Board is damaged.
 CR Motor driver failure
Does the CR Encoder work properly? Check it using
the Service Program.
1. Replace the CR Encoder. (Page 166)
2. Replace the CR Motor. (Page 161)
3. Replace the SUB Board. (Page 131)
4. Replace the Main Board. (Page 123)
Table 2-4. Troubleshooting for Service Call Error
Code Error Name Cause Check Item Remedy
