Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
TROUBLE SHOOTING Remedies for Service Call Error 46
SE Group Confidential (Related Staff Only)
113F
CR Motor
lock error
The CR Motor was driven at a speed abnormally
slower than a predetermined one during operation.
 CR Encoder cable is damaged.
 CR Motor cable is damaged.
 Irregular load
 CR Encoder failure
 CR Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 CR Encoder to SUB Board (CN102)
 CR Motor to SUB-M Board (CN1)
2. Does the CR Encoder work properly? Check it
using the Service Program.
1. Replace the CR Encoder.
(Page 166)
2. Replace the CR Motor. (Page 161)
1229
PF Motor
oscillation error
The control terminal (Vre terminal) of the PF Motor
driver has shorted out.
1. Is the PF Motor driver on the Main Board
damaged?
2. Is there any foreign materials around the PF Motor
driver?
1. Remove the foreign material.
2. If the error still occurs, replace the Main Board.
(Page 123)
122A
PF Motor
overload error
Overcurrent to the PF Motor was detected.
 PF Encoder cable is damaged.
 PF Motor cable is damaged.
 Irregular load
 PF Encoder failure
 PF Motor failure
Does the PF Encoder work properly? Check it using
the Service Program.
1. Replace the PF Encoder.
(Page 215)
2. Replace the Main Board. (Page 123)
122B
PF Motor
over speed error
 Contamination of PF Encoder
 Increase of load (paper jam)
 Cable disconnection
1. Is the PF Encoder contaminated?
2. Is there any foreign materials on the paper path?
3. Check the Interface cable for breaking.
1. Replace the PF Encoder.
(Page 215)
2. Replace the FFC of the PF Encoder.
3. Replace the PF Motor.
(Page 213)
122C
PF Motor
reversing error
PF Motor rotated in the reverse direction.
---
Replace the PF Motor.
(Page 213)
122D
PF Motor
driving time-out error
Abnormally-long driving duration of the PF Motor
was detected.
 Irregular load
 Firmware becomes out of control.
---
Replace the Main Board. (Page 123)
Table 2-4. Troubleshooting for Service Call Error
Code Error Name Cause Check Item Remedy
