Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
TROUBLE SHOOTING Remedies for Service Call Error 50
SE Group Confidential (Related Staff Only)
1433 IC Holder 2 life error
The IC Holder 2 has reached the end of its service
life. (The total number of times the ink cartridge is
removed from the printer has reached a predetermined
limit)
---
Replace the IC Holder 2 (Page 189) and reset the
counter (Page 293).
1435
Ink Path CR Assy
life error
The Ink Path CR Assy has reached the end of its
service life.
---
Replace the Ink Path CR Assy (Page 140) and reset
the counter (Page 293).
1410
Pump Cap Unit 1
undetectable error
Pump Cap Unit 1 failure Is the sensor cable properly connected? Replace the Pump Cap Unit 1. (Page 170)
1411
Pump Cap Unit 2
undetectable error
Pump Cap Unit 2 failure Is the sensor cable properly connected? Replace the Pump Cap Unit 2.
(Page 177)
1417
Wrong ink mixture
error
Wrong color ink was filled in the ink tank. This error
occurs if the combination of the ink holder and the
chip unit is not correct.
Check if wrong color ink is filled (check if the
combination of the ink holder and the chip unit is
correct.)
Discard the current ink tank, and clean the ink path
using cleaning liquid, then install a new ink tank.
(Page 72)
150C
PG position
undetectable error
When changing the PG, the PG sensor could not
detect the PG position.
1. Is the PG Sensor out of order? Does the light
shielding plate react to the sensor?
2. Do the planetary gearing work normally? Do the
planet gears and outer gears properly engage with
each other?
3. Is the CR Unit out of its home position?
1. Replace the PG Sensor.
(Page 169)
2. Replace the APG Assy. (Page 167)
3. Remove any obstacles around the CR Unit home
position. The printer changes the PG with the CR
Unit being at its home position.
1519
APG Motor
oscillation error
The control terminal (Vre terminal) of the APG Motor
driver has shorted out.
1. Is the APG Motor driver on the Main Board
damaged?
2. Is there any foreign materials around the APG
Motor driver?
1. Remove the foreign material.
2. If the error still occurs, replace the Main Board.
(Page 123)
151A
APG Motor
overload error
 Connection failure of the APG Motor.
 Overcurrent to the APG Motor was detected.
 APG Motor cable is damaged.
 Irregular load
 APG encoder failure
 APG Motor failure
Is there any problems such as damaged cable in the
connections below?
 APG Motor (APG encoder) to Main Board
(CN210/CN203)
Replace the APG Motor. (Page 167)
Table 2-4. Troubleshooting for Service Call Error
Code Error Name Cause Check Item Remedy
