Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
TROUBLE SHOOTING Remedies for Service Call Error 59
SE Group Confidential (Related Staff Only)
15A9
Reel Motor
oscillation error
The control terminal (Vre terminal) of the Reel Motor
driver has shorted out.
1. Is the Reel Motor driver on the Main Board
damaged?
2. Is there any foreign materials around the Reel
Motor driver?
1. Remove the foreign material.
2. If the error still occurs, replace the Main Board.
(Page 123)
15AA
Reel Motor
overload error
Overcurrent to the Reel Motor was detected.
 Reel Motor cable disconnection.
 Irregular load
 Reel Motor encoder failure
 Reel Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 Reel Motor to Sub-F Board (CN601)
2. Does the Reel Motor encoder work properly?
Check it using the Service Program.
Replace the Reel Motor. (Page 249)
15AB
Reel Motor
over speed error
The Reel Motor was driven at a speed faster than a
predetermined one during deceleration.
 Irregular load
 Reel Motor encoder failure
 Sub-F Board failure
 Reel Motor driver failure
Does the Reel Motor encoder work properly? Check it
using the Service Program.
1. Replace the Reel Motor.
(Page 249)
2. Replace the Sub-F Board. (Page 247)
3. Replace the Main Board. (Page 123)
15AC
Reel Motor
reversing error
The number of occurrences of reversing the Reel
Motor has reached a predetermined limit.
 The polarity of Reel Motor cable is opposite.
 Reel Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 Reel Motor to Sub-F Board (CN601)
2. Does the Reel Motor encoder work properly?
Check it using the Service Program.
Replace the Reel Motor. (Page 249)
15AD
Reel Motor
driving time-out error
Abnormally-long driving duration of the Reel Motor
was detected.
 Irregular load
 Firmware becomes out of control.
---
Replace the Main Board. (Page 123)
Table 2-4. Troubleshooting for Service Call Error
Code Error Name Cause Check Item Remedy
