Epson SC-F9200 series Service Manual

SC-F9200 Series Revision C
TROUBLE SHOOTING Remedies for Service Call Error 60
SE Group Confidential (Related Staff Only)
15AE
Reel Motor
velocity deviation error
The Reel Motor was driven at a speed abnormally
faster than a predetermined one during acceleration or
deceleration.
 Irregular load
 Reel Motor encoder failure
 Reel Motor failure
 Sub-F Board failure
 Reel Motor driver failure
Does the Reel Motor encoder work properly? Check it
using the Service Program.
1. Replace the Reel Motor.
(Page 249)
2. Replace the Sub-F Board. (Page 247)
3. Replace the Main Board. (Page 123)
15AF
Reel Motor
lock error
 Connection failure of the Reel Motor.
 The Reel Motor was driven at a speed abnormally
slower than a predetermined one during operation.
 Irregular load
 Reel Motor encoder failure
 Reel Motor failure
1. Is there any problems such as damaged cable in the
connections below?
 Reel Motor to Sub-F Board (CN601)
2. Does the Reel Motor encoder work properly?
Check it using the Service Program.
Replace the Reel Motor. (Page 249)
1620
Pressurizing
initialization error
The initialization process did not complete within a
predetermined time period.
1. Is there any abnormal load applied to the Pressure
Unit?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the Pressure Unit (Ink Holder).
(Page
183, 189)
2. Replace the Main Board. (Page 123)
1621
Pressurizing/Suction
switching error
The pressurizing and suction processes did not
complete within a predetermined time period.
1. Is there any abnormal load applied to the Pressure
Unit?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the Pressure Unit (Ink Holder).
(Page
183, 189)
2. Replace the Main Board. (Page 123)
1622
Operating time-out
error
The switching operation did not complete within a
predetermined time period.
1. Is there any abnormal load applied to the Pressure
Unit?
2. Is there any disconnected connectors or damaged
cables?
1. Replace the Pressure Unit (Ink Holder).
(Page
183, 189)
2. Replace the Main Board. (Page 123)
1623
Continuous revolution
error
The control terminal (Vre terminal) of the Pressure
Motor driver has shorted out.
1. Is the Pressure Motor driver on the Main Board
damaged?
2. Is there any foreign materials around the Pressure
Motor driver?
1. Remove the foreign material.
2. If the error still occurs, replace the Main Board.
(Page 123)
Table 2-4. Troubleshooting for Service Call Error
Code Error Name Cause Check Item Remedy
