Page #183 background image
SC-F9200 Series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 183
SE Group Confidential (Related Staff Only)
3.4.5.17 Ink Holder 1
REQUIRED TOOL
Ink Cartridge for service (4 pcs)
USB cable
Service program
Communication driver
PREPARATION BEFORE REPLACEMENT
1. Start the printer in the Serviceman Mode.
Turn on the printer while pressing [Menu] + [Back] + [OK].
2. Start the service program and select When replace ink holder from
ADJUSTMENT (Sequence).
3. Select Ink Holder Counter.
Press the [Run] button to reset the counter.
(p293)
4. Turn off the printer.
5. Turn on the printer.
6. Discard the waste ink.
7. Select Switch between Ink cartridges and Ink tanks.
Select Single channel -> Ink Holder 1 (Home) -> Cyan/Yellow, Magenta/
Black and Ink Cartridge for service, and press the [Run] button to validate the
ink cartridges for service. (p329)
8. Turn off the printer.
9. Remove all the ink tanks. (p207)
10. Lower all the lock levers.
11. Start the printer in the Serviceman Mode.
Turn on the printer while pressing [Menu] + [Back] + [OK].
12. Select Ink Eject.
Select Single channel -> Ink Holder 1 (Home) -> Cyan/Yellow, Magenta/
Black, and press the [Run] button to run the ink eject. (p332)
13. Turn off the printer.
REPLACEMENT
1. Remove the Media Loading Lever. (p210)
2.
Remove the Panel Unit. (p101)
3.
Remove the Right Upper Cover. (p103)
4.
Remove the Ink Tank. (p207)
5.
Remove the Lower Ink Holder. (p106)
6.
Remove the Right Front Cover. (p107)
7.
Remove the Right Cover. (p108)
8.
Remove the Board Box Cover. (p117)
9.
Remove the Power Supply Board Box. (See from Step 2 to Step 11 in
“3.4.4.3 PSH Board/PSH-B Board” (Page 125))
10. Remove the cable cover. (See Step 8 in “3.4.5.16 Pump Cap Unit 2” (Page
177))
11. Open the three clamps.
12. On the front side, release the cable from the two relay connectors (No.1
and No.21).
A D J U S T M E N T
R E Q U I R E D
When replacing/removing this part, refer to “4.1.2 Adjustment
Items and the Order by Repaired Part” (p260) and make sure to
perform the specified operations including required adjustment.
