EPSON Stylus COLOR 860/1160 Revision C
Adjustment Overview 118
5.1.2 Adjustment Tools Required
Table 5-3 below shows adjustment tools for Stylus COLOR 860/1160.
Table 5-3 Adjustment Tools Required
No. Name Adjustment Item Contents/Spec.
1 Thickness Gauge Parallelism Adjustment thickness:1.14 mm
2 Micro scoop Backlash Adjustment Magnified ratio: x 15
Scale:0.1mm
3 Adjustment Program Each Mechanism Settings Stylus COLOR 760
860 1160
Program Disk;
3.5inch 2 FDD
CAUTION
n Never use the bent (curved or tilted) or rusty thickness
gauge.
n Erase any dirt, grease or obstacles on the thickness gauge
before you use it.
