Epson Stylus Color 1160 User Manual

EPSON Stylus COLOR 860/1160 Revision C
PRODUCT DESCRIPTION INTERFACE 15
NOTE: In/Out refers to the direction of signal flow seen from the printer
side.
18 Logic H - Out
Pulled up to +5V via 3.9 K ohm
resistor.
35 +5V - Out
Pulled up to +5V via 3.3K ohm
resistor.
17
Chassis
GND
- - Chassis GND
16,33,
19-30
GND - - Signal GND
15,34 NC - - Not connected
Table 1-6. Connector Pin Assignment and Signals (continued)
Pin No.
Signal
Name
Return
GND Pin
In/Out Functional Description
