Specifications Page 158
Parallel Interface
Your printer is equipped with an 8-bit parallel interface, with the
following characteristics:
Forward channel Data format: 8-bit parallel, IEEE-1284 compatibility mode
Synchronization: STROBE pulse
Handshake timing: BUSY and ACKNLG signals
Signal level: TTL compatible
Connector: 57-30360 Amphenol connector or equivalent
Reverse channel Transmission mode: IEEE-1284 Nibble mode
Adaptable connector: 57-30360 Amphenol connector or equivalent
Synchronization: Refer to the IEEE-1284 specification
Handshaking: Refer to the IEEE-1284 specification
Signal level: IEEE-1284 Level 1 device, TTL compatible
Data transmission timing: Refer to the IEEE-1284 specification
