DISASSEMBLY & ASSEMBLY Parts Diagram 193
Confidential
Figure 4-10. Auto Take-up Reel
Take-up Reel Cover
(p313)
Power Supply Board
(p318)
Main Board
(p318)
Take-up Reel Motor
(p320)
Take-up Reel Sensor
(p314)
Take-up Reel Switch
(p316)
Take-up Reel LED
(p315)
