Appendix
Character Specifications
Slip printing
Receipt printing
Number of characters Alphanumeric characters: 95
Extended graphics: 128 × 12 pages (including user-defined
page)
International characters: 18 character types
Character structure
(W x H dots)
Font A 5 × 9 dots
Font B 7 × 9 dots
Endorsement
font
5 × 7 dots
Character size
(W x H)
Font A 1.56 × 3.11 mm
Font B 1.24 × 3.11 mm
Endorsement
font
1.09 × 2.41 mm
Number of characters Alphanumeric characters: 95
Extended graphics: 128 × 12 pages (including user-defined
page)
International characters: 18 character types
Character structure
(W x H dots)
Font A 12 × 24 dots (including 2-dot horizontal spacing)
Font B 9 × 17 dots (including 2-dot horizontal spacing)
Font C 10 × 20 dots (including 1-dot horizontal spacing)
Character size
(W x H)
Font A Standard: 1.41 × 3.39 mm
Double-height: 1.41 × 6.77 mm
Double-width: 2.82 × 3.39 mm
Double-width, double-height: 2.82 × 6.77 mm
Font B Standard: 0.99 × 2.40 mm
Double-height: 0.99 × 4.80 mm
Double-width: 1.98 × 2.40 mm
Double-width, double-height: 1.98 × 4.80 mm
Font C 1.27×2.82 mm
Space between characters is not included.
Characters can be scaled up to 64 times as large as the standard size.
