58
Chapter 3 Advanced Usage
3
When Another Interface is Connected
DIP Switch Bank 1
DIP Switch Bank 2
If the interface is a powered-USB
SW Function ON OFF
Default
setting
1-1 Auto line feed Always enabled Always disabled OFF
1-2 Receive buffer capacity 45 bytes 4 KB OFF
1-3 Reserved - - OFF
1-4
1-7
Reserved (Do not change settings) - - OFF
1-8 Reserved - - OFF
SW Function ON OFF
Default
setting
2-1 Handshaking (BUSY condition) Receive buffer full
Offline
Receive buffer full
OFF
2-2 Customer display (DM-D) connection Connected Not connected OFF
2-3
2-4
Selects print density
See
"Selecting the Print Density (DIP Switches 2-3/2-4)"
on page 59
.
OFF
2-5 Reserved - - OFF
2-6 Reserved (Do not change settings) Fixed to OFF OFF
2-7 Reserved (Do not change settings) Fixed to OFF OFF
2-8 Reserved (Do not change settings)
Fixed to ON ON
Fixed to OFF
*
OFF
To Next Page
