Chapter 3 Advanced Usage
3
DIP Switch Bank 2
SW Function ON OFF
Default
setting
2-1 Handshaking (BUSY condition) Receive buffer full
Offline
Receive buffer full
OFF
2-2 Customer display (DM-D) connection Connected Not connected OFF
2-3
2-4
Selects print density
See
"Selecting the Print Density (DIP Switches 2-3/2-4)"
on page 59
.
OFF
OFF
2-5 Reserved (Do not change setting) Fixed to OFF OFF
2-6 Reserved (Do not change setting) Fixed to OFF OFF
2-7 I/F pin 6 reset signal Enabled Disabled OFF
2-8 IF pin 25 reset signal Enabled Disabled OFF
For DIP Switch 2-1 (BUSY condition), see also
"Selecting the BUSY Status" on page 59.
