Chapter 3 Advanced Usage
3
NV Graphics Information Print Mode
Prints the following NV graphic information registered to the printer.
Capacity of the NV graphics
Used capacity of the NV graphics
Unused capacity of the NV graphics
Number of NV graphics that are registered
Key code, number of dots in X direction, number of dots in Y direction to be defined.
NV graphics data
Follow the steps below.
1
After running a self-test, hold down the Feed button for at least one second, and then
select the Mode selection.
The Mode selection guidance is printed, and the Paper LED flashes.
2
After briefly (less than one second) pressing the Feed button once, hold it down for at
least one second, to print the NV graphics information.
After information printing, the Mode selection guidance is printed again.
3
To finish, turn off the power, or select “Exit and Reboot Printer”.
For details on NV graphics, see "NV Graphics Memory" on page 22.
