Epson TM-U220-i Technical Reference Guide

107
Chapter 3 Application Development Information
3
Web Service Settings - Server Access - Direct Print
You can set server direct print for the TM-U220-i.
Item Description
Server Direct Print Sets whether to use the Server Direct Print function or not.
Select [Enable] or [disable].
ID Set ID for the server-side program to identify TM-U220-i when [Server
Direct Print] is set to [Enable].
This ID becomes the user ID used for Digest access authentication.
The set value will also be passed as an ID parameter value for the form
data posted to the server.
Password Set the user ID and password used for Digest authentication. Make sure
to set a password as Digest authentication cannot be performed for the
user ID without a password.
Server1 to 3 URL Specifies the Web server URL and the application path when [Server
Direct Print] is set to [Enable].
Example: http://[IP address of Web server]/Test_print.php
Click the [Access Test] button to check if the address is accessible.
Interval(s) Set the request interval when [Server Direct Print] is set to [Enable].
Authenticate Server Sets whether the server authentication is performed with the registered
certificate when accessed through https.
Apply Saves settings to TM-U220-i.

Epson TM-U220-i Specifications

General

Type	POS printer
Color	Yes
Print technology	Dot matrix
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Maximum roll diameter	83 mm
Standard interfaces	Ethernet, Parallel, RS-232, RS-485, USB, Wireless LAN
Serial interface type	RS-232, RS-485
Connectivity technology	Wired & Wireless
Electromagnetic compatibility	VCCI class A, FCC class A, CE marking, AS/NZS 3548 class B
Mean cycles between failures (MCBF)	18000000
Safety	UL, CSA, TÜV (EN60950)
Mean time between failures (MTBF)	180000 h
Product color	Gray

Weight and Dimensions

Depth	248 mm
Width	160 mm
Height	138.5 mm
