Appendix

Printable Area

76 mm paper width printing

Maximum 200 dots,

400 positions

(6.8)

(5.8)

63.4

34.9

Cutting position (autocutter)

Cutting position (manual cutter)

[Units: mm]

All the numeric values are typical.
