138
*1: It is recommended to feed 2.116 mm {0.083"} or more in advance before printing to prevent dot displacement after
cutting.
Changing between partial cut and full cut is not controlled by a software command.
*2: When the optional wireless LAN cable set (OT-WL01) is used.
*3: A clock function is embedded in Intelligent Interface. When the power is off, this is backed up using a battery.
Buffers Receive buffer 4K bytes / 40 bytes: selectable
NV bit image 128K bytes
User NV memory 8K bytes
Power supply 24 V DC ±7%
Life
(Printer unit)
Mechanism 7.5 million lines
Print head 150 million characters
When printing at an average of 2 dots per wire per character.
Autocutter 800,000 cuts
End of life is defined as the point at which the printer reaches
the beginning of the wear out period
MTBF 180,000 hours
Failure is defined as a random failure occurring at the time of
the random failure period.
MCBF 18 million lines
This is an average failure interval based on failures related to
wear out and random failures up to the life of 7.5 million lines.
Life
(Intelligent
Interface)
MTBF 180,000 hours
RTC
*3
Battery life 5 years or longer
Temperature/humidity Operating: 0 to 50°C {32 to 122°F}, 10 to 90% RH
Storage: -10 to 50°C {14 to 122°F}, 10 to 90% RH
Overall dimensions 160 mm × 248 mm × 138.5 mm {6.3” × 5.5” × 9.8”} (W × D × H)
Weight (mass) Approx. 2.5 kg {5.51 lb} (excluding paper, ribbon, and AC
adapter)
