Epson TM-U220-i Technical Reference Guide

44
1
Make sure the power supply is disconnected.
2
Open the roll paper cover.
3
Take off the roll paper guide from the printer by loosening the two screws.
4
Push the roll paper guide on the appropriate width.
Roll paper guide
C
B
A
Roll paper guide
position of fixing the screws
A: 76 mm width
B: 69.5 mm width
C: 57.5 mm width

Epson TM-U220-i Specifications

General

Type	POS printer
Color	Yes
Print technology	Dot matrix
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Maximum roll diameter	83 mm
Standard interfaces	Ethernet, Parallel, RS-232, RS-485, USB, Wireless LAN
Serial interface type	RS-232, RS-485
Connectivity technology	Wired & Wireless
Electromagnetic compatibility	VCCI class A, FCC class A, CE marking, AS/NZS 3548 class B
Mean cycles between failures (MCBF)	18000000
Safety	UL, CSA, TÜV (EN60950)
Mean time between failures (MTBF)	180000 h
Product color	Gray

Weight and Dimensions

Depth	248 mm
Width	160 mm
Height	138.5 mm
