Epson TM-U220-i Technical Reference Guide

66
5. Set up a wireless LAN
For a wireless LAN, select the [System Settings] menu and [Wireless], and set the items such as SSID
and Security Mode.
After setting, click [Apply] at the bottom of the screen. Then the settings are written to the product. If
[Apply] is not clicked, the settings are not applied. ( U "System Settings - Network - Wireless" on
page 111)
6. Connect via a wireless LAN
To use a wireless LAN, disconnect the LAN cable from this product after setting is finished.
 Be sure to change the SSID from the default value.
 For security protection, encryption setting is strongly recommended.
This product cannot be used with the wired LAN connection and wireless LAN connection at the
same time. The wired LAN connection has a priority.

Epson TM-U220-i Specifications

General

Type	POS printer
Color	Yes
Print technology	Dot matrix
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Maximum roll diameter	83 mm
Standard interfaces	Ethernet, Parallel, RS-232, RS-485, USB, Wireless LAN
Serial interface type	RS-232, RS-485
Connectivity technology	Wired & Wireless
Electromagnetic compatibility	VCCI class A, FCC class A, CE marking, AS/NZS 3548 class B
Mean cycles between failures (MCBF)	18000000
Safety	UL, CSA, TÜV (EN60950)
Mean time between failures (MTBF)	180000 h
Product color	Gray

Weight and Dimensions

Depth	248 mm
Width	160 mm
Height	138.5 mm
