TM-U220A
Specification
(For Argentina Fiscal)
App.12 App.11
Figure E.2 shows the drive signal waveform generated when the drawer is driven according to the
above conditions.
Figure E.2 Drawer Drive Signal Waveform
200 ms
α
= 300 ms 500 ms
ON
OFF
