a. Maintenance box
b. Rear cover (Auto Duplexer)
c. AC inlet
d. LINE port
e. EXT. port
f. LAN port
g. USB connector
Guide to the Control Panel
Note:
❏ Control panel design varies depending on location.
❏ Although the control panel design and what displayed on the LCD screen such as menu names and option names may
differ from your actual product, the method of operation is the same.
WF-7610 Series/WF-7620 Series
User’s Guide
Getting to Know Your Product
21
