ergoflix LX - Security Device against Unauthorised Use; Technical Data; Technical Specifications; Dimensions and Weight

2.10.5. Security device against unauthorised use
To prevent the theft of the wheelchair, we recommend securing it with a chain lock. The best way to
do this is to use one of the rear wheels, which can be used to connect the lock to a fixed object.
3. Technical specifications
In the following tables you will find a list of the technical data of the equipment.
WARNING
Dangers of exceeding or falling below
specified operating parameters
If the technical data specified below is exceeded or not met, dangerous situations may arise and
persons may be endangered. To avoid this, please note the following:
• The equipment may only be used up to the max. operating parameters specified below.
• The operator must ensure that the operating parameters for media (electrical system) are
maintained permanently and sufficiently fail-safe.
3.1. Dimensions and weight
Dimensions (approx.) unfolded folded
Length 995 mm 350 mm
Width 615 mm - 670 mm 615 mm - 670 mm
Height 935 mm 780 mm
Seat dimensions (approx.) from to
Width 480 mm 560 mm
Depth 420 mm
Height 510 mm
Backrest height 460 mm
Weight without battery with battery
kilogram 25.1 kg 28.1 kg
Load capacity maximum
kilogram 145 kg
Angle Seat angle Backrest angle
Angle 4° 98°
ergoflix.de | 17
